SINO-Professional OEM/ODM/SKD EV Charging Solution Provider More Than 16 Years.
Ac Charging Station with Custom Services
Product details of the ac charging station
Quick Overview
SINO ac charging station comes in various innovative design styles. The product has been inspected in conformity with international quality standards. The ac charging station developed by our company can be applied in different fields. The reliable quality of the product ensures stable development prospects.
Product Introduction
Compared with similar products, the ac charging station of SINO is more strict in the selection of raw materials. The specific aspects are as follows.
Future Smart Charging Network
Our charging stations not only support conventional charging methods but also smart charging management to improve charging efficiency, save energy costs and boosting revenue for businesses. It was integrated with OCPP 1.6J smart system and communicate by WI-FI, 4G, Ethernet to monitor all communication data in the charging process, realize smart charging and easy maintenance. The user-friendly LCD display, ensures easy activation through Plug & Play, mobile App, or RFID card, perfectly tailored to meet commercial charging needs, Energize Your Charging convenience
Private and commercial operation of EV charging stations
The Wall Mounted EV Charger with OCPP function is a versatile electric vehicle charging device designed for commercial and public charging applications. Its main feature is the OCPP (Open Charge Point Protocol) function, which enables it to integrate with multiple backend management systems and charge point operators. It normally supports most of electric vehicles with plug connector IEC 62195-2 (Type 2) and J1772 type 1.These chargers offer higher power, reducing charging times and ensuring your vehicle is quickly charged.
Main Features
Product display
Model PEVC2107 AC EV Charger Are Ideal For
Product parameter
| Electrical Properties | |||||||
| Input Voltage | 230Vac ±10% or 400Vac±10% | ||||||
| Input Current | 16A or 32A | ||||||
| Output Voltage | 230Vac ±10% or 400Vac±10% | ||||||
| Output Current | 16A or 32A | ||||||
| Rated Power | 7.4kW / 11kW / 22kW | ||||||
| User Interface & Control | |||||||
| LCD Display | 4.3" Color TouchScreen( Optional ) | ||||||
| User Authentication | Plug & Play / RFID / APP | ||||||
| Charger Connector | IEC 62196-2 Type 2 (SAEJ1772 Type 1 Optional) | ||||||
| Energy Measuring | Embedded meter, with 1% accuracy | ||||||
| Communication | |||||||
| Backend | Bluetooth / Wi-Fi (4G / Ethernet Optional ) | ||||||
| Backend Protocol | OCPP 1.6 J (OCPP2.x Coming soon) | ||||||
| Protection | |||||||
| Residual Current Protection | Type A 30mA+DC 6mA | ||||||
| Electrical Protection |
Over/Under Voltage Protection,Over Current Protection, Short Circuit Protec-tion, Over Temperature Protection, Lightning Protection, Ground Fault,Surge Protection |
||||||
| Mechanical & Packing | |||||||
| IP, IK Level | IP55, IK08 | ||||||
| Product Dimension | 270mm*135mm*365mm( W*D*H ) | ||||||
| Package Dimension | 330mm*274mm*500mm( W*D*H ) | ||||||
| Weight | 5.6kg( Net ) / 7.2kg( Gross ) | ||||||
| Certifications & Standard | |||||||
| Standard | EN 61851-1 2019, IEC 62955 2018, IEC 61008-1 2010, IEC/EN 62196-1 | ||||||
| Certificate | TUV, CE | ||||||
